Sandvik Coromant - 109mm Max Drill Depth, 3xD, 35mm Diam, Indexable Insert Drill - 2 Inserts, C5 Modular Connection Shank
Item #: 49333453
Brand: Sandvik Coromant
Model #: 5765407
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | 880 |
| Drill Diameter (mm) | 35.00 |
| Drill Diameter (Decimal Inch) | 1.3780 |
| Maximum Drill Depth (mm) | 109.00 |
| Maximum Drill Depth (Decimal Inch) | 4.2913 |
| Shank Type | Modular Connection |
| Modular Connection Size | C5 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 3xD |
| Toolholder Material | Steel |
| Number of Drill Inserts | 2 |
| Maximum Drill Diameter (Decimal Inch) | 1.3780 |
| Maximum Drill Diameter (mm) | 36.00 |
| Overall Length/Projection (mm) | 185.00 |
| Overall Length/Projection (Decimal Inch) | 7.2835 |
| Insert Compatibility | 880-060406H-C-GM; 880-0604W06H-P-GM |
| Flute Length (mm) | 105.00 |
| Flute Length (Decimal Inch) | 4.1339 |
| Body Length (Decimal Inch) | 6.0776 |
| Body Length (mm) | 154.37 |
| Shank Length (mm) | 30.63 |
| Shank Length (Decimal Inch) | 1.2059 |
| Series | CoroDrill 880 |
| Radial Adjustment (-mm) | 0.50 |
