Sandvik Coromant - 97mm Max Drill Depth, 3xD, 31mm Diam, Indexable Insert Drill - 2 Inserts, C6 Modular Connection Shank
Item #: 49333958
Brand: Sandvik Coromant
Model #: 5765351
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Drill Style | 880 |
| Drill Diameter (mm) | 31.00 |
| Drill Diameter (Decimal Inch) | 1.2205 |
| Maximum Drill Depth (mm) | 97.00 |
| Maximum Drill Depth (Decimal Inch) | 3.8189 |
| Shank Type | Modular Connection |
| Modular Connection Size | C6 |
| Cutting Direction | Right Hand |
| Through Coolant | Through Coolant |
| Drill Depth by Diameter Ratio | 3xD |
| Toolholder Material | Steel |
| Number of Drill Inserts | 2 |
| Maximum Drill Diameter (Decimal Inch) | 1.2205 |
| Maximum Drill Diameter (mm) | 33.00 |
| Overall Length/Projection (mm) | 181.00 |
| Overall Length/Projection (Decimal Inch) | 7.1260 |
| Insert Compatibility | 880-060406H-C-GM; 880-0604W06H-P-GM |
| Flute Length (mm) | 93.00 |
| Flute Length (Decimal Inch) | 3.6614 |
| Body Length (Decimal Inch) | 5.6063 |
| Body Length (mm) | 142.40 |
| Shank Length (mm) | 38.60 |
| Shank Length (Decimal Inch) | 1.5196 |
| Series | CoroDrill 880 |
| Radial Adjustment (-mm) | 0.99 |
