Sandvik Coromant - Internal Thread, Right Hand Cut, 5/8" Shank Width x 14.3mm Shank Height Indexable Threading Toolholder - 6" OAL, Various Insert Compatibility, R166.0L Toolholder, Series T-Max U-Lock 166
Item #: 49379068
Brand: Sandvik Coromant
Model #: 5742014
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Thread Type | Internal |
| Hand of Holder | Right Hand |
| Shank Width/Diameter (Decimal Inch) | 0.6250 |
| Shank Width/Diameter (Inch) | 5/8 |
| Shank Height (mm) | 14.30 |
| Shank Height (Decimal Inch) | 0.5630 |
| Overall Length (Decimal Inch) | 6.0000 |
| Overall Length (Inch) | 6 |
| Insert Compatibility | R166.0L-11MM01-050; R166.0L-11MM01-100; R166.0L-11MM01-150; R166.0L-11MM01-200; R166.0L-11NT01F140; R166.0L-11NT01F180; R166.0L-11UN01-140; R166.0L-11UN01-160; R166.0L-11UN01-180; R166.0L-11UN01-200; R166.0L-11UN01-240; R166.0L-11UN01-280; R166.0L-11UN01- |
| Series | T-Max U-Lock 166 |
| Toolholder Style | R166.0L |
| Through Coolant | No |
| Multi-Use Tool | Yes |
| Multi-Use Application | Threading |
| Insert Holding Method | Screw |
| Center to Cutting Edge (Decimal Inch) | 0.4130 |
| Neck Diameter (Decimal Inch) | 0.6250 |
| Head Length (Decimal Inch) | 1.0300 |
| Shank Length (Decimal Inch) | 5.1669 |
| Maximum Bore Depth (Decimal Inch) | 1.8750 |
| Minimum Bore Diameter (Decimal Inch) | 0.6300 |
| Insert Inscribed Circle (Inch) | 1/4 |
| Insert Inscribed Circle (Decimal Inch) | 0.2500 |
| Pitch Range | 32 - 12 |
| Toolholder Material | Steel |
| Minimum Bore Diameter (mm) | 16 |
