Sandvik Coromant - Arbor Hole Connection, 0.0787" Cutting Width, 0.8701" Depth of Cut, 3" Cutter Diam, 0.3937" Hole Diam, 5 Tooth Indexable Slotting Cutter - AQD..Y..C Toolholder, E Insert, Right Hand Cutting Direction
Item #: 49409451
Brand: Sandvik Coromant
Model #: 6657543
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 2.00 |
| Cutting Width (Decimal Inch) | 0.0787 |
| Maximum Depth of Cut (mm) | 22.10 |
| Maximum Depth of Cut (Decimal Inch) | 0.8701 |
| Cutter Diameter (Decimal Inch) | 3.0000 |
| Cutter Diameter (Inch) | 3 |
| Hole Diameter (mm) | 10.00 |
| Hole Diameter (Decimal Inch) | 0.3937 |
| Modular Connection Size | X10 |
| Number of Teeth | 5 |
| Toolholder Style | AQD..Y..C |
| Series | CoroMill QD |
| Insert Style | E |
| Staggered Tooth | No |
| Number of Cutter Inserts | 5 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Maximum RPM | 4400 |
| Lead Angle | 90 |
| Maximum Body Diameter (Decimal Inch) | 3.0000 |
| Weldon Flat | No |
| Through Coolant | Yes |
| Manufacturers Catalog Number | 6657543 |
| Complete Insert Compatibility1 | QD-NE-0200-020E-PM |
| Overall Height (mm) | 2.65 |
| Overall Height (Decimal Inch) | 0.1043 |
| Arbor Hole Diameter (Decimal Inch) | 0.3937 |
