Sandvik Coromant - 3 Inserts, 2.0079" Cutter Diam, 0.2362" Max Depth of Cut, Indexable High-Feed Face Mill - 0.8661" Arbor Hole Diam, 0.4094" Keyway Width, R200..Qxx Toolholder, RCKT 12 04 M0 Inserts, Series CoroMill 200
Item #: 49522774
Brand: Sandvik Coromant
Model #: 5742598
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 2.0079 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362 |
| Arbor Hole Diameter (Decimal Inch) | 0.8661 |
| Series | CoroMill 200 |
| Cutter Style | R200..Qxx |
| Number of Cutter Inserts | 3 |
| Insert Compatibility | RCKT 12 04 M0 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Maximum RPM | 16200 |
| Maximum Body Diameter (Decimal Inch) | 2.4803 |
| Through Coolant | No |
| Complete Insert Compatibility | RCKT 12 04 M0 |
| Keyway Width (Decimal Inch) | 0.4094 |
