Sandvik Coromant - 66mm Cutting Diam, 6mm Max Depth of Cut, C6 Modular Connection, Indexable Copy End Mill - Screw Holding Method, R300-1240.. Insert Style, R300..Cx Toolholder, Through Coolant
Item #: 49539034
Brand: Sandvik Coromant
Model #: 5744293
Exact Tooling IR#: 04
Features and Benefits
Modular connections allow for single end mill to accept various shank diameters without changing machine toolholding set-ups.
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 66.00 |
| Maximum Depth of Cut (mm) | 6.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362 |
| Shank Type | Modular Connection |
| Number of Cutter Inserts | 5 |
| Insert Style | R300-1240.. |
| Toolholder Style | R300..Cx |
| Overall Length (mm) | 88.00 |
| Overall Length (Decimal Inch) | 3.4646 |
| Insert Holding Method | Screw |
| Through Coolant | Through Coolant |
| Number of Flutes | 5 |
| Minimum Cutting Diameter (mm) | 54.00 |
| Head Length (Decimal Inch) | 1.9685 |
| Maximum RPM | 21700 |
| Maximum Cutting Diameter (Decimal Inch) | 2.59842 |
| Minimum Cutting Diameter (Decimal Inch) | 2.126 |
| Projection (mm) | 50.00 |
| Projection (Decimal Inch) | 1.9685 |
| Modular Connection Size | C6 |
