Kyocera - 40mm Cut Diam, 6mm Max Depth of Cut, 40mm OAL, Indexable Square Shoulder End Mill - BDMT 0703 Inserts, 90° Lead Angle, Through Coolant
Item #: 50388487
Brand: Kyocera
Model #: 8822925
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 40.00 |
| Cutting Diameter (Decimal Inch) | 1.5748 |
| Overall Length/Projection (mm) | 40.00 |
| Overall Length/Projection (Decimal Inch) | 1.5748 |
| Lead Angle | 90 |
| Through Coolant | Coolant Through |
| Maximum Depth of Cut (mm) | 6.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.236220 |
| Number of Cutter Inserts | 10 |
| Insert Holding Method | Screw |
| End Mill Type | End Mill |
| Cutter Style | MECX |
| Number of Flutes | 10 |
| Insert Compatibility | BDMT 0703 |
| Maximum RPM | 30500 |
