Kyocera - 10 Inserts, 3" Cut Diam, 0.551" Arbor Diam, 0.236" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 70° Lead Angle, 2.48" High, PNEA 1106, PNEG 1106 & PNMG 1106 Insert Compatibility
Item #: 50389527
Brand: Kyocera
Model #: 8842514
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 3.0000 |
| Arbor Hole Diameter (Decimal Inch) | 0.5510 |
| Lead Angle | 70 |
| Overall Height (Decimal Inch) | 2.4800 |
| Insert Compatibility | PNEA 1106; PNEG 1106; PNMG 1106 |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.2360 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 10 |
| Insert Holding Method | Wedge |
| Cutter Style | MFK |
| Number of Flutes | 10 |
| Cutting Rake Angle | -7 |
| Rake | Negative |
| Hub Diameter (Decimal Inch) | 2.7500 |
| Keyway Width (Decimal Inch) | 0.3820 |
| Keyway Depth (Decimal Inch) | 0.2400 |
| Pitch | Extra Fine |
| Counterbore Diameter (Decimal Inch) | 0.8660 |
| Complete Insert Compatibility | PNEA 1106XNTN-T01020; PNEG 1106XNEN-GL; PNEG 1106XNER-W; PNEG 1106XNTR-T00515; PNMG 1106XNEN-GH; PNMG 1106XNEN-GM |
