Kyocera - 6 Inserts, 4" Cut Diam, 1-1/2" Arbor Diam, 0.925" Max Depth of Cut, Indexable Square-Shoulder Face Mill - 90° Lead Angle, 1.97" High, APMT 2506 Insert Compatibility
Item #: 50423672
Brand: Kyocera
Model #: 8824755
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 4.0000 |
| Arbor Hole Diameter (Decimal Inch) | 1.5000 |
| Lead Angle | 90 |
| Overall Height (Decimal Inch) | 1.9700 |
| Insert Compatibility | APMT 2506 |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.9250 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | MSR |
| Number of Flutes | 6 |
| Cutting Rake Angle | -5 |
| Rake | Negative |
| Keyway Width (Decimal Inch) | 0.5000 |
| Keyway Depth (Decimal Inch) | 0.3100 |
| Counterbore Diameter (Decimal Inch) | 1.6100 |
| Complete Insert Compatibility | APMT 250608ER-NB3; APMT 250608ER-NB4; APMT 250616EL-NB3; APMT 250616EL-NB4; APMT 250616ER-NB3; APMT 250616ER-NB3P; APMT 250616ER-NB4; APMT 250616ER-NB4P; APMT 250640ER-NB3; APMT 250640ER-NB4 |
