Kyocera - 32TGF Grade PR930, 0.75mm Cutting Width Carbide Grooving Insert - 2mm Max Depth of Cut, Right Hand, 0.1mm Corner Radius, TiCN Finish - Exact Tooling

Kyocera - 32TGF Grade PR930, 0.75mm Cutting Width Carbide Grooving Insert - 2mm Max Depth of Cut, Right Hand, 0.1mm Corner Radius, TiCN Finish

Item #: 50471481

Brand: Kyocera

Model #: 8821178

Features and Benefits

Solid carbide is extremely heat resistant and used for high speed applications. It is commonly used on cast iron, nonferrous materials, plastics and other tough-to-machine materials.

Product Specifications
Insert Style TGF
Insert Size 32
Material Carbide
Cutting Width (mm) 0.75
Cutting Width (Decimal Inch) 0.0295
Maximum Depth of Cut (mm) 2.00
Maximum Depth of Cut (Decimal Inch) 0.0787
Material Grade Super Micrograin
Manufacturer's Grade PR930
Coating TiCN
Cutting Direction Right Hand
Insert Hand Right Hand
Relief Angle 2
Multi-Use Tool No
Corner Radius (mm) 0.10
Corner Radius (Decimal Inch) 0.003937
Coating Process PVD
Series TGF
Manufacturers Catalog Number TGF32R075-010
Insert Thickness (Decimal Inch) 0.1252
Insert Thickness (mm) 3.1800
