Schneider Electric - 3 Pole, 230 Coil VAC at 50/60 Hz, 25 Amp at 440 VAC and 40 Amp at 440 VAC, Nonreversible IEC Contactor

Item #: 50908698
Brand: Schneider Electric
Model #: LC1D25P7

Product Specifications

Number of Poles 3

Coil Voltage 230 VAC @ 50/60 Hz

Amperage 25 @ 440 VAC; 40 @ 440 VAC

Action NonReversible

Horsepower at 1 Phase 2 @ 115 VAC; 3 @ 230/240 VAC

Horsepower at 3 Phase 15 @ 460/480 VAC; 20 @ 575/600 VAC; 5 @ 200/208 VAC; 7.5 @ 230/240 VAC

Auxiliary Contacts NO/NC

Overall Height (mm) 85

Overall Width (mm) 45

Overall Depth (mm) 92

Standards Met Bureau Veritas; CCC; CSA; CSA C22.2 No. 14; DNV; EN/IEC 60947-4-1; EN/IEC 60947-5-1; GL; GOST; LROS; RINA; RoHS Compliant; UL 508; UL Listed
