Scientific Cutting Tools - 1/2-20" Port, 0.95" Spotface Diam, 5/16" Tube Outside Diam, Reamer Pilot, Carbide Tipped Porting Tool
Item #: 44039717
Brand: Scientific Cutting Tools
Model #: AND10050-5RL
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | AND 10050 |
| Pilot Type | Reamer |
| Port Thread Size (Decimal Inch) | 0.5000-20 |
| Port Thread Size (Inch) | 1/2-20 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 5.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 0.313 |
| Tube Outside Diameter Compatibility (Inch) | 5/16 |
| Minimum Pilot Diameter (Decimal Inch) | 0.4490 |
| Maximum Pilot Diameter (Decimal Inch) | 0.5195 |
| Spotface Diameter (Decimal Inch) | 0.9500 |
| Pilot Length (Decimal Inch) | 0.5270 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | Bright |
| Head Length (Decimal Inch) | 1.2400 |
| Overall Length (Decimal Inch) | 3.1200 |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Shank Length (Decimal Inch) | 1.8800 |
| Seal Angle | 30 |
| Thread Type | UNF |
| Flute Type | Straight |
| Number of Flutes | 4 |
