Tool-Flo - FLSLT, External, Left Hand, 0.44" Max Depth of Cut, Indexable Grooving Tool Holder - FLGT-3L Insert Compatibility, 1" Shank Height, 1" Shank Width, 6" OAL
Item #: 51108900
Brand: Tool-Flo
Model #: 93421616D
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Internal or External | External |
| Toolholder Type | Face Grooving |
| Hand of Holder | Left Hand |
| Maximum Depth of Cut (Decimal Inch) | 0.4400 |
| Overall Length (Decimal Inch) | 6.0000 |
| Toolholder Style | FLSLT |
| Insert Compatibility | FLGT-3L |
| Shank Height (Decimal Inch) | 1.0000 |
| Shank Width/Diameter (Decimal Inch) | 1.0000 |
| Series | Flo-Lock |
| Through Coolant | Non Coolant Through |
| Multi-Use Tool | No |
| Insert Holding Method | Clamp |
| Back of Bar to Cutting Edge (Decimal Inch) | 1.2500 |
| Manufacturers Catalog Number | FLSLT-163D |
| Complete Insert Compatibility | FLGT-3094L; FLGT-3125L; FLGT-3189L; FLGT-330L; FLGT-340L |
