Sandvik Coromant - 7 Inserts, 2.3701" Cutter Diam, 0.315" Max Depth of Cut, Indexable High-Feed Face Mill - 3.8583" High, RA300..Cx Toolholder, R300-1648.. Inserts, Series CoroMill 300
Item #: 51498590
Brand: Sandvik Coromant
Model #: 5738745
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 2.3701 |
| Maximum Depth of Cut (Decimal Inch) | 0.3150 |
| Shank Diameter (Decimal Inch) | 63.0000 |
| Overall Height (Decimal Inch) | 3.8583 |
| Series | CoroMill 300 |
| Cutter Style | RA300..Cx |
| Number of Cutter Inserts | 7 |
| Insert Compatibility | R300-1648.. |
| Cutting Direction | Right Hand |
| Maximum RPM | 16000 |
| Maximum Body Diameter (Decimal Inch) | 2.5630 |
| Through Coolant | Yes |
| Complete Insert Compatibility | R300-1648.. |
| Manufacturers Catalog Number | 5738745 |
