Corner Radius End Mill: 5/8″ Dia, 1-1/4″ LOC, 0.03″ Radius, 4 Flutes 3-3/8″ OAL, 5/8″ Shank Dia, Variable ° Helix, AlTiN Coated, Corner Radius End
Item #: 52175304
Brand: HAIMER
Model #: F1004NNL5/8ZR.0
Product Specifications
| Mill Diameter (Decimal Inch) | 0.6250; 0.625 in |
| Mill Diameter (Inch) | 5/8; 0.625 in |
| End Type | Corner Radius |
| Corner Radius (Decimal Inch) | 0.0300 |
| Number of Flutes | 4 |
| Finish/Coating | AlTiN |
| Length of Cut (Decimal Inch) | 1.2500 |
| Length of Cut (Inch) | 1-1/4 |
| Shank Diameter (Inch) | 5/8 in; 5/8 |
| Overall Length (Inch) | 3-3/8 |
| Extended Reach | Yes |
| Helix Angle | Variable |
| Reach Length (Decimal Inch) | 1.56 in |
| Reach Length (Inch) | 1.56 in; 1-9/16 |
| Neck Diameter (Decimal Inch) | 0.5930; 0.593 in |
| Material Grade | Submicron |
| Single or Double End | Single |
| Cutting Direction | Right Hand |
| Flute Direction | Right Hand |
| Shank Diameter Tolerance (Decimal Inch) | 5/8 in |
| Overall Length Tolerance (Decimal Inch) | +0.0020 to -0.0020 in; +0.002/-0.002 |
| Overall Length Tolerance (mm) | +0.0020 to -0.0020 in |
