Emuge - DIN69871-50 Taper Shank Rigid Tapping Adapter - M10 Min Tap Capacity, 85mm Projection, Through Coolant
Item #: 52354461
Brand: Emuge
Model #: F3134653.1.24
Exact Tooling IR#: 04
Features and Benefits
Rigid or solid tapping styles are used for general purpose CNC machining. The rigid tapping cycle synchronizes the machine and spindle rotation to match a specific thread pitch. It is used at higher speeds, but does not compensate for length during the taping cycle.
Taper shanks maintain balance and rigidity during high speeds and heavy-duty applications. They have smaller diameters than straight shanks.
| Product Specifications | |
|---|---|
| Tapping Style | Rigid |
| Shank Type | Taper Shank |
| Taper Size | DIN69871-50 |
| Minimum Tap Capacity (mm) | M10 |
| Projection (Decimal Inch) | 3.3465 |
| Projection (mm) | 85.00 |
| Quick Change | No |
| Minimum Collet Capacity (mm) | 7.00 |
| Minimum Collet Capacity (Decimal Inch) | 0.2756 |
| Maximum Collet Capacity (Decimal Inch) | 0.8661 |
| Maximum Collet Capacity (mm) | 22.00 |
| Collet System | ER Tap |
| Holder Series | KSN4/Synchro |
| Nose Diameter (mm) | 63.00 |
| Nose Diameter (Decimal Inch) | 2.4803 |
| Tap Depth (mm) | 31.00 |
| Overall Length (mm) | 186.75 |
| Overall Length (Decimal Inch) | 7.3524 |
| Through Coolant | Yes |
