Emuge - HSK63A Taper Shank Rigid Tapping Adapter - M4 Min Tap Capacity, 76mm Projection, Through Coolant
Item #: 52355047
Brand: Emuge
Model #: F3133C04.1.30
Exact Tooling IR#: 04
Features and Benefits
Rigid or solid tapping styles are used for general purpose CNC machining. The rigid tapping cycle synchronizes the machine and spindle rotation to match a specific thread pitch. It is used at higher speeds, but does not compensate for length during the taping cycle.
Taper shanks maintain balance and rigidity during high speeds and heavy-duty applications. They have smaller diameters than straight shanks.
| Product Specifications | |
|---|---|
| Tapping Style | Rigid |
| Shank Type | Taper Shank |
| Taper Size | HSK63A |
| Minimum Tap Capacity (mm) | M4 |
| Projection (Decimal Inch) | 2.9921 |
| Projection (mm) | 76.00 |
| Quick Change | No |
| Minimum Collet Capacity (mm) | 4.50 |
| Minimum Collet Capacity (Decimal Inch) | 0.1772 |
| Maximum Collet Capacity (Decimal Inch) | 0.6299 |
| Maximum Collet Capacity (mm) | 16.00 |
| Collet System | ER Tap |
| Holder Series | KSN3/Synchro |
| Nose Diameter (mm) | 50.00 |
| Nose Diameter (Decimal Inch) | 1.9685 |
| Tap Depth (mm) | 29.00 |
| Overall Length (mm) | 108.00 |
| Overall Length (Decimal Inch) | 4.2520 |
| Through Coolant | Yes |
