Emuge - HSK63A Taper Shank Tension & Compression Tapping Chuck - M4 Min Tap Capacity, 147mm Projection, Through Coolant
Item #: 52355591
Brand: Emuge
Model #: F3233C04.1
Exact Tooling IR#: 04
Features and Benefits
Tension and compression tapping styles are engineered to automatically compensate for machine feed, pitch and tap rates. They feature a spring design that allows the tap to float during the cutting cycle without affecting the pitch.
Taper shanks maintain balance and rigidity during high speeds and heavy-duty applications. They have smaller diameters than straight shanks.
| Product Specifications | |
|---|---|
| Tapping Style | Tension & Compression |
| Shank Type | Taper Shank |
| Taper Size | HSK63A |
| Minimum Tap Capacity (mm) | M4 |
| Projection (Decimal Inch) | 5.7874 |
| Projection (mm) | 147.00 |
| Quick Change | No |
| Minimum Collet Capacity (mm) | 4.50 |
| Minimum Collet Capacity (Decimal Inch) | 0.1772 |
| Maximum Collet Capacity (Decimal Inch) | 0.6299 |
| Maximum Collet Capacity (mm) | 16.00 |
| Collet System | ER Tap |
| Holder Series | KSN3/HD/ER |
| Nose Diameter (mm) | 50.00 |
| Nose Diameter (Decimal Inch) | 1.9685 |
| Tap Depth (mm) | 29.00 |
| Tension (mm) | 10.00 |
| Compression (Decimal Inch) | 0.2756 |
| Compression (mm) | 7.00 |
| Overall Length (mm) | 179.00 |
| Overall Length (Decimal Inch) | 7.0472 |
| Through Coolant | Yes |
