Iscar - Shell Mount A Connection, 0.31" Cutting Width, 0.88" Depth of Cut, 3" Cutter Diam, 3/4" Hole Diam, 6 Tooth Indexable Slotting Cutter - FDN Toolholder, X/QOMT 060204-HQ Insert
Item #: 52708401
Brand: Iscar
Model #: 3100871
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount A |
| Cutting Width (Decimal Inch) | 0.3100 |
| Maximum Depth of Cut (Decimal Inch) | 0.8800 |
| Cutter Diameter (Decimal Inch) | 3.0000 |
| Cutter Diameter (Inch) | 3 |
| Hole Diameter (Inch) | 3/4 |
| Hole Diameter (Decimal Inch) | 0.7500 |
| Number of Teeth | 6 |
| Toolholder Style | FDN |
| Series | Heliquad(FDN) |
| Insert Style | X/QOMT 060204-HQ |
| Number of Cutter Inserts | 12 |
| Insert Holding Method | Screw |
| Minimum Cutting Width (Decimal Inch) | 0.3100 |
| Maximum Cutting Width (Decimal Inch) | 0.3100 |
| Hub Diameter (Decimal Inch) | 1.7700 |
| Radius | No |
| Manufacturers Catalog Number | FDN D3.0-0.31-06-R06 |
| Complete Insert Compatibility1 | QOMT 060204-HQ; XOMT 060204-HQ |
