Iscar - 6 Inserts, 80mm Cut Diam, 27mm Arbor Diam, 18mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0/90° Lead Angle, 50mm High, TPKN 2204 Insert Compatibility, Series IscarMill
Item #: 52709128
Brand: Iscar
Model #: 3100107
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 80.00 |
| Cutting Diameter (Decimal Inch) | 3.1496 |
| Arbor Hole Diameter (mm) | 27.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.0630 |
| Lead Angle | 0/90 |
| Overall Height (mm) | 50.00 |
| Overall Height (Decimal Inch) | 1.9685 |
| Insert Compatibility | TPKN 2204 |
| Series | IscarMill |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 18.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.7087 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Clamp |
| Cutter Style | F90 |
| Number of Flutes | 6 |
| Keyway Width (mm) | 12.40 |
| Keyway Width (Decimal Inch) | 0.4882 |
| Complete Insert Compatibility | TPKN 2204PD-R; TPKN 2204PDFR; TPKN 2204PDTL; TPKN 2204PDTR; TPKN 2204PDTR-42 |
