Iscar - Arbor Hole Connection, 0.3937" Depth of Cut, 50mm Cutter Diam, 0.315" Hole Diam, 4 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSFN Insert
Item #: 52733813
Brand: Iscar
Model #: 2301359
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Maximum Depth of Cut (mm) | 10.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937 |
| Cutter Diameter (mm) | 50.00 |
| Cutter Diameter (Decimal Inch) | 1.9685 |
| Hole Diameter (mm) | 8.00 |
| Hole Diameter (Decimal Inch) | 0.3150 |
| Number of Teeth | 4 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSFN |
| Staggered Tooth | No |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 1600 |
| Minimum Cutting Width (Decimal Inch) | 0.1394 |
| Maximum Cutting Width (Decimal Inch) | 0.1780 |
| Maximum Cutting Width (mm) | 4.52 |
| Hub Diameter (mm) | 28.00 |
| Hub Diameter (Decimal Inch) | 1.1024 |
