Iscar - Arbor Hole Connection, 3.3071" Depth of Cut, 250mm Cutter Diam, 1.5748" Hole Diam, 18 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSF. Insert
Item #: 52734050
Brand: Iscar
Model #: 2300701
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Maximum Depth of Cut (mm) | 84.00 |
| Maximum Depth of Cut (Decimal Inch) | 3.3071 |
| Cutter Diameter (mm) | 250.00 |
| Cutter Diameter (Decimal Inch) | 9.8425 |
| Hole Diameter (mm) | 40.00 |
| Hole Diameter (Decimal Inch) | 1.5748 |
| Number of Teeth | 18 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSF. |
| Staggered Tooth | No |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 320 |
| Minimum Cutting Width (Decimal Inch) | 0.1063 |
| Maximum Cutting Width (Decimal Inch) | 0.1390 |
| Maximum Cutting Width (mm) | 3.53 |
| Hub Diameter (mm) | 80.00 |
| Hub Diameter (Decimal Inch) | 3.1496 |
