Iscar - Arbor Hole Connection, 4.6063" Depth of Cut, 315mm Cutter Diam, 1.5748" Hole Diam, 22 Tooth Indexable Slotting Cutter - SGSF Toolholder, GSFN Insert
Item #: 52734092
Brand: Iscar
Model #: 2301164
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Maximum Depth of Cut (mm) | 117.00 |
| Maximum Depth of Cut (Decimal Inch) | 4.6063 |
| Cutter Diameter (mm) | 315.00 |
| Cutter Diameter (Decimal Inch) | 12.4016 |
| Hole Diameter (mm) | 40.00 |
| Hole Diameter (Decimal Inch) | 1.5748 |
| Number of Teeth | 22 |
| Toolholder Style | SGSF |
| Series | Self-Grip(SGSA) |
| Insert Style | GSFN |
| Staggered Tooth | No |
| Insert Holding Method | Self Clamping |
| Maximum RPM | 250 |
| Minimum Cutting Width (Decimal Inch) | 0.2169 |
| Maximum Cutting Width (Decimal Inch) | 0.2559 |
| Maximum Cutting Width (mm) | 6.50 |
| Hub Diameter (mm) | 80.00 |
| Hub Diameter (Decimal Inch) | 3.1496 |
