Cleveland - #24 118° High Speed Steel Jobber Drill - Exact Tooling

Cleveland - #24 118° High Speed Steel Jobber Drill


Item #: 85192284
Brand: Cleveland
Model #: C73452

Features and Benefits

High speed steel (HSS) provides good wear resistance and can be used in general purpose applications for both ferrous and nonferrous materials.
Bright provides a smooth, polished finish on the tool. It increases chip flow in softer materials such as aluminum, wood and plastic.
Spiral flutes are constructed with a higher flute angle to remove chips more easily.
Product Specifications
Drill Bit Size (Wire) #24
Drill Bit Size (Decimal Inch) 0.1520
Drill Point Angle 118
Drill Bit Material High Speed Steel
Drill Bit Finish/Coating Bright
Flute Type Spiral
Cutting Direction Right Hand
Shank Type Straight
Coolant Through No
Flute Length (Inch) 2
Flute Length (mm) 50.80
Flute Length (Decimal Inch) 2.0000
Overall Length (Inch) 3-1/8
Point Type Split Point
Shank Diameter (Decimal Inch) 0.1520
Spiral Type Regular Spiral
Specification Designation NAS
Web Configuration Tapered
Drill Bit Diameter Tolerance (Decimal Inch) -0.0007 to 0.0000
Web Thinning Web-Thinned
Specification Number NAS 907
Drill Bit Grade Heavy-Duty
Series/List 2228
$ 2.24
