Scientific Cutting Tools - 9/16-18" Port, 1.012" Spotface Diam, 3/8" Tube Outside Diam, Reamer Pilot, Carbide Tipped Porting Tool
Item #: 44039683
Brand: Scientific Cutting Tools
Model #: AND10050-6RA
Features and Benefits
Carbide-tipped cuts faster than high speed steel. It is commonly used on ferrous and nonferrous materials including cast iron, steel and steel alloys.
| Product Specifications | |
|---|---|
| Port Standard Designation | AND 10050 |
| Pilot Type | Reamer |
| Port Thread Size (Decimal Inch) | 0.5620-18 |
| Port Thread Size (Inch) | 9/16-18 |
| Tool Material | Carbide-Tipped |
| Tube Dash Number | 6.000 |
| Tube Outside Diameter Compatibility (Decimal Inch) | 0.375 |
| Tube Outside Diameter Compatibility (Inch) | 3/8 |
| Minimum Pilot Diameter (Decimal Inch) | 0.5060 |
| Maximum Pilot Diameter (Decimal Inch) | 0.5825 |
| Spotface Diameter (Decimal Inch) | 1.0120 |
| Pilot Length (Decimal Inch) | 0.5390 |
| Identification Groove | No |
| Workpiece Compatibility | Tubes |
| Finish/Coating | AlTiN+ |
| Head Length (Decimal Inch) | 1.5000 |
| Overall Length (Decimal Inch) | 3.3800 |
| Shank Diameter (Decimal Inch) | 0.5000 |
| Shank Length (Decimal Inch) | 1.8800 |
| Seal Angle | 30 |
| Thread Type | UNF |
| Flute Type | Straight |
| Number of Flutes | 4 |
