Walter - Arbor Hole Connection, 1.1417" Cutting Width, 0.4724" Depth of Cut, 125mm Cutter Diam, 1.5748" Hole Diam, 6 Tooth Indexable Slotting Cutter - F4153.B Toolholder, LN.U 100508 Insert, Right Hand Cutting Direction
Item #: 53055703
Brand: Walter
Model #: 5325465
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 29.00 |
| Cutting Width (Decimal Inch) | 1.1417 |
| Maximum Depth of Cut (mm) | 12.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.4724 |
| Cutter Diameter (mm) | 125.00 |
| Cutter Diameter (Decimal Inch) | 4.9213 |
| Hole Diameter (mm) | 40.00 |
| Hole Diameter (Decimal Inch) | 1.5748 |
| Number of Teeth | 6 |
| Toolholder Style | F4153.B |
| Series | Xtra-tec |
| Insert Style | LN.U 100508 |
| Staggered Tooth | No |
| Number of Cutter Inserts | 12 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Hub Diameter (mm) | 65.00 |
| Hub Diameter (Decimal Inch) | 2.5591 |
| Keyway Width (Decimal Inch) | 0.3937 |
| Keyway Width (mm) | 10.00 |
| Radius | No |
| Manufacturers Catalog Number | F4153.B40.125.Z06.10 |
| Complete Insert Compatibility1 | LNHU100508-B57T; LNHU100508-F57T; LNMU100508-B57T; LNMU100508-F57T |
