Walter - Arbor Hole Connection, 2.4016" Cutting Width, 0.4724" Depth of Cut, 200mm Cutter Diam, 1.9685" Hole Diam, 8 Tooth Indexable Slotting Cutter - F4153.B Toolholder, LN.U 100508 Insert, Right Hand Cutting Direction
Item #: 53055711
Brand: Walter
Model #: 5325467
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 61.00 |
| Cutting Width (Decimal Inch) | 2.4016 |
| Maximum Depth of Cut (mm) | 12.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.4724 |
| Cutter Diameter (mm) | 200.00 |
| Cutter Diameter (Decimal Inch) | 7.8740 |
| Hole Diameter (mm) | 50.00 |
| Hole Diameter (Decimal Inch) | 1.9685 |
| Number of Teeth | 8 |
| Toolholder Style | F4153.B |
| Series | Xtra-tec |
| Insert Style | LN.U 100508 |
| Staggered Tooth | No |
| Number of Cutter Inserts | 16 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Hub Diameter (mm) | 75.00 |
| Hub Diameter (Decimal Inch) | 2.9528 |
| Keyway Width (Decimal Inch) | 0.4724 |
| Keyway Width (mm) | 12.00 |
| Radius | No |
| Manufacturers Catalog Number | F4153.B50.200.Z08.10 |
| Complete Insert Compatibility1 | LNHU100508-B57T; LNHU100508-F57T; LNMU100508-B57T; LNMU100508-F57T |
