US Motors - 1/2 hp, TEAO Enclosure, No Thermal Protection, 1,140 RPM, 208-230/460 Volt, 60 Hz, Three Phase Standard Efficient Motor - Size 56 Frame, Cradle/Stud Mount, 1 Speed, Ball Bearings, 2.4-2.4/1.2 Full Load Amps, B Class Insulation, Reversible
Item #: 53655387
Brand: US Motors
Model #: 8458
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Motor Type | Three Phase Standard Efficient |
| Type of Enclosure | TEAO |
| Horsepower | 1/2 |
| Thermal Protection Rating | None |
| Name Plate RPMs | 1140 |
| Voltage | 208-230/460 |
| Frequency Hz | 60 |
| Frame Size | 56 |
| Mount Type | Cradle/Stud |
| Number of Speeds | 1 |
| Bearing Type | Ball |
| Applications | HVAC |
| Full Load Amperage | 2.4-2.4/1.2 |
| Insulation Class | B |
| Frame Material | Steel |
| Overall Length (Decimal Inch) | 10.7000 |
| Full Load Efficiency Rating | 79.3 |
| Service Factor Rating | 1 |
| Motor Rotation | Reversible |
| PSC Code | 6105 |
