Sumitomo - 3" Cut Diam, 1" Arbor Hole, 0.314" Max Depth of Cut, 25° Indexable Chamfer & Angle Face Mill - 6 Inserts, SNMT 1205 Insert, Right Hand Cut, Series SumiMill
Item #: 53966685
Brand: Sumitomo
Model #: 2200W0K
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Decimal Inch) | 3.0000 |
| Arbor Hole Diameter (Decimal Inch) | 1.0000 |
| Lead Angle | 25 |
| Overall Height (Decimal Inch) | 1.7500 |
| Insert Compatibility | SNMT 1205 |
| Series | SumiMill |
| Through Coolant | No |
| Maximum Depth of Cut (Decimal Inch) | 0.3140 |
| Number of Cutter Inserts | 6 |
| Insert Holding Method | Screw |
| Cutter Style | DNX |
| Hub Diameter (Decimal Inch) | 2.2500 |
| Keyway Width (Decimal Inch) | 0.3750 |
| Maximum Body Diameter (Decimal Inch) | 3.3030 |
| Cutting Direction | Right Hand |
| Pitch | Coarse |
| Complete Insert Compatibility | SNMT 1205ZNEN |
