Sumitomo - 50mm Cut Diam, 22mm Arbor Hole, 45° Indexable Chamfer & Angle Face Mill - 4 Inserts, ONMT 05T6\xB6SNMT 13T6\xB6XNET 13T6 Insert, Right Hand Cut, Through Coolant, Series DualMill
Item #: 53966800
Brand: Sumitomo
Model #: 2200AFT
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 50.00 |
| Cutting Diameter (Decimal Inch) | 1.9685 |
| Arbor Hole Diameter (mm) | 22.00 |
| Arbor Hole Diameter (Decimal Inch) | 0.8661 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 1.5748 |
| Overall Height (mm) | 40.00 |
| Insert Compatibility | ONMT 05T6; SNMT 13T6; XNET 13T6 |
| Series | DualMill |
| Through Coolant | Yes |
| Number of Cutter Inserts | 4 |
| Insert Holding Method | Screw |
| Cutter Style | DGCM |
| Cutting Rake Angle | -10 (Radial); -5 (Axial) |
| Rake | Negative |
| Hub Diameter (Decimal Inch) | 1.5748 |
| Hub Diameter (mm) | 40.00 |
| Keyway Width (mm) | 10.40 |
| Keyway Width (Decimal Inch) | 0.4094 |
| Maximum Body Diameter (Decimal Inch) | 2.5197 |
| Cutting Direction | Right Hand |
| Pitch | Fine |
| Counterbore Diameter (Decimal Inch) | 0.7087 |
| Complete Insert Compatibility | ONMT 05T6ANER; SNMT 13T6ANER; XNET 13T6ANEN |
