Sandvik Coromant - TRVB1304 F Grade H13A Carbide Turning Insert - Uncoated, 35° Triangle, 13mm Inscr Circle, 3/16" Thick, 1/64" Corner Radius
Item #: 54912464
Brand: Sandvik Coromant
Model #: 5755409
Exact Tooling IR#: 04
Features and Benefits
Solid carbide is extremely heat-resistant and used for high speed applications on cast iron, nonferrous materials, plastics and other tough-to-machine materials.
| Product Specifications | |
|---|---|
| Insert Style | TRVB |
| Insert Size | 1304 |
| Material | Carbide |
| Length (mm) | 13.00 |
| Length (Decimal Inch) | 0.5118 |
| Inscribed Circle (mm) | 13.00 |
| Inscribed Circle (Decimal Inch) | 0.5118 |
| Thickness (Inch) | 3/16 |
| Thickness (Decimal Inch) | 0.1874 |
| Thickness (mm) | 4.76 |
| Corner Radius (Inch) | 1/64 |
| Corner Radius (mm) | 0.40 |
| Corner Radius (Decimal Inch) | 0.0157 |
| Manufacturer's Grade | H13A |
| Coating | Uncoated |
| Chip Breaker | F |
| Hole Diameter (mm) | 3.40 |
| Hole Diameter (Decimal Inch) | 0.1339 |
| ISO Number | TRVB1304FH13A |
| Relief Angle | 5 |
| Manufacturers Catalog Number | 5755409 |
| Primary Workpiece Material | K; N; S |
| Included Angle | 35 |
| Cutting Direction | Neutral |
| Insert Hand | Neutral |
| Series | CoroTurn TR |
| Maximum Depth of Cut (mm) | 12.60 |
| Maximum Depth of Cut (Decimal Inch) | 0.4961 |
| Insert Holding Method | Screw |
| Shape | Triangle |
