Accurate Bushing - 26mm Roller Diam x 12mm Width, 10mm Stud Diam x 23mm Length, Sealed Stud Cam Follower with Hex - Carbon Steel, 12mm Thread Length, M10 x 1 Thread, 36mm OAL, 8,600 N Dynamic Cap, 12,900 N Static Cap
Item #: 55246904
Brand: Accurate Bushing
Model #: MCRV-26-SB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower with Hex |
| Roller Diameter (mm) | 26.000 |
| Roller Width (mm) | 12 |
| Stud Diameter (mm) | 10.00 |
| Dynamic Load Capacity (N) | 8600 |
| Static Load Capacity | 12900 |
| Length (mm) | 36.00 |
| Thread Size | M10 x 1 |
| Material | Carbon Steel |
| Stud Length (mm) | 23.00 |
| Thread Length (mm) | 12.00 |
| Roller Type | Full Complement |
