Accurate Bushing - 3-1/2" Roller Diam x 2" Width, 1-3/8" Stud Diam x 2-3/4" Length, Sealed Stud Cam Follower with Hex - Carbon Steel, 1-3/8" Thread Length, 1-3/8-12 Thread, 4-3/4" OAL, 24,660 Lb Dynamic Cap, 31,800 Lb Static Cap
Item #: 55249585
Brand: Accurate Bushing
Model #: CR-3-1/2-XB
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Sealed Stud Cam Follower with Hex |
| Roller Diameter (Decimal Inch) | 3.5000 |
| Roller Diameter (Inch) | 3-1/2 |
| Roller Width (Decimal Inch) | 2.0000 |
| Stud Diameter (Decimal Inch) | 1.3750 |
| Dynamic Load Capacity (Lb.) | 24660 |
| Static Load Capacity (Pounds) | 31800.00 |
| Length (Decimal Inch) | 4.750 |
| Thread Size | 1-3/8-12 |
| Material | Carbon Steel |
| Stud Length (Decimal Inch) | 2.7500 |
| Stud Length (Inch) | 2-3/4 |
| Thread Length (Inch) | 1-3/8 |
| Hex Size (Inch) | 5/8 |
