Royal Products - MT5 Morse Taper, 2.45" Head Diam Live Center - 5,000 Max RPM, 2.78" Head Length, 1-1/2" Point Diam, 1-1/4" Point Len, 2,240 Lb Max Workpc, Female Point
Item #: 56272529
Brand: Royal Products
Model #: 10497
Exact Tooling IR#: 04
Features and Benefits
Female live centers have internal threads and are interchangeable with other points for general purpose turning operations.
| Product Specifications | |
|---|---|
| Shank Type | Morse Taper |
| Taper Size | MT5 |
| Maximum Workpiece Weight (Lb.) | 2240.00 |
| Point Style | Female |
| Point Diameter (Inch) | 1-1/2 |
| Point Diameter (Decimal Inch) | 1.5000 |
| Point Length (Decimal Inch) | 1.2500 |
| Thrust Load (Lb.) | 2150.00 |
| Radial Load (Lb.) | 2240.00 |
| Head Diameter (Decimal Inch) | 2.4500 |
| Head Length (Decimal Inch) | 2.7800 |
| Maximum RPM | 5000 |
| Carbide-Tipped | No |
