Schneider Electric - 3 Pole, 127 Coil VAC at 50-400 Hz and 127 Coil VDC, 170 Amp at 440 VAC, 185 Amp at 440 VAC and 275 Amp at 440 VAC, Nonreversible IEC Contactor
Item #: 56807498
Brand: Schneider Electric
Model #: CR1F185G7
Exact Tooling IR#: 04
Features and Benefits
Non-reversing contactors are designed with one phase line that connects to and runs voltage through the motor. The contactor is used to turn a motor on and off.
Product Specifications
3 Pole, 127 Coil VAC at 50-400 Hz and 127 Coil VDC, 170 Amp at 440 VAC, 185 Amp at 440 VAC and 275 Amp at 440 VAC, Nonreversible IEC Contactor -
| Number of Poles | 3 |
| Coil Voltage | 127 VAC @ 50-400 Hz; 127 VDC |
| Amperage | 170 @ 440 VAC; 185 @ 440 VAC; 275 @ 440 VAC |
| Action | NonReversible |
| Overall Height (mm) | 174 |
| Overall Width (mm) | 168 |
| Overall Depth (mm) | 181 |
