Palmgren - 3-in-1 Machines; Swing Over Bed (Inch): 11 ; Distance Between Centers (mm): 685.80 ; Distance Between Centers (Inch): 27 ; Swing Over Cross Slide (Inch): 3.4900 ; Cross Slide Travel (Inch): 7 ; Spindle Bore Diameter (Inch): 1.0200
Item #: 56853039
Brand: Palmgren
Model #: 9684520
Product Specifications
3-in-1 Machines; Swing Over Bed (Inch): 11 ; Distance Between Centers (mm): 685.80 ; Distance Between Centers (Inch): 27 ; Swing Over Cross Slide (Inch): 3.4900 ; Cross Slide Travel (Inch): 7 ; Spindle Bore Diameter (Inch): 1.0200
| Swing Over Bed (Inch) | 11 |
| Distance Between Centers (mm) | 685.80 |
| Distance Between Centers (Inch) | 27 |
| Swing Over Cross Slide (Inch) | 3.4900 |
| Cross Slide Travel (Inch) | 7 |
| Spindle Bore Diameter (Inch) | 1.0200 |
| Spindle Bore Diameter (Decimal Inch) | 6.8900 |
| Spindle Nose Designation | 4MT |
| Headstock Taper Size | 4MT |
| Number of Spindle Speeds (Turning) | 6 |
| Minimum Turning Spindle Speed (RPM) | 100.00 |
| Maximum Turning Spindle Speed (RPM) | 3,000.00 |
| Tailstock Taper Size | 2MT |
| Tailstock Travel Length (Inch) | 4 |
| Tailstock Travel Length (Decimal Inch) | 4.1300 |
| Number of Inch Threads | 21 |
| Minimum Number of Inch Threads (TPI) | 8 |
| Maximum Number of Inch Threads (TPI) | 56 |
| Number of Metric Threads | 21 |
| Minimum Number of Metric Threads (Decimal Inch) | 0.2000 |
| Maximum Number of Metric Threads (Decimal Inch) | 4.0000 |
| Min. Longitudinal Feed Per Rev. (Decimal Inch) | 0.0020 |
| Maximum Drilling Capacity in Steel (Inch) | 1/4 |
| Table Width (Inch) | 6 |
| Table Length (Inch) | 10 |
| Number of T-Slots | 2 |
| Longitudinal Travel (Decimal Inch) | 6.8900 |
| Quill Diameter (Decimal Inch) | 2.3635 |
| Spindle Travel Length (Inch) | 2 |
| Number of Mill Drill Spindle Speeds | Variable |
| Minimum Mill Drill Spindle Speed (RPM) | 100.00 |
| Maximum Mill Drill Spindle Speed (RPM) | 3,000.00 |
| Maximum Spindle to Table Distance (Inch) | 14.5700 |
| Spindle to Column Distance (Inch) | 6-3/8 |
| Spindle to Column Distance (Decimal Inch) | 14.5700 |
| Head Rotation (Degrees) | 90.00 |
| Phase | 1 |
| Horsepower (HP) | 1 |
| Voltage | 115 |
| Overall Length (Decimal Inch) | 26.3800 |
| Overall Length (Inch) | 26-3/4 |
| Overall Depth (Decimal Inch) | 21.6500 |
