Hydraulic Hose Fittings & Couplings; Type: H-Series ISO-B Poppet Valve Female Threaded Coupler; Fitting Type: Coupler; Hose Inside Diameter (Decimal Inch): 0.5625; Hose Size: 9/16
Item #: 55371686
Brand: Dixon Valve & Coupling
Model #: 2HOF3
Product Specifications
| Type | H-Series ISO-B Poppet Valve Female Threaded Coupler |
| Fitting Type | Coupler |
| Hose Inside Diameter (Decimal Inch) | 0.5625 |
| Hose Size | 9/16 |
| Material | Steel |
| Thread Type | SAE |
| Thread Size (Inch) | 9/16-18 |
| Shape | Straight |
| Connection Type | Threaded |
| Maximum Working Pressure (Psi - 3 Decimals) | 5000.000 |
| Overall Length (Decimal Inch) | 2.2900 |
| Epa Watersense Certified | No |
| Series | H ISO-B |
| Valve/Non-Valved | Valved |
| Body Diameter (Inch) | 1/4 |
| Hose Diameter (Inch) | 9/16 |
| UNSPSC Code | 40141734 |
| Type | H-Series ISO-B Poppet Valve Female Threaded Coupler |
| Fitting Type | Coupler |
| Hose Inside Diameter (Decimal Inch) | 0.5625 |
| Hose Size | 9/16 |
| Material | Steel |
| Thread Type | SAE |
| Thread Size (Inch) | 9/16-18 |
| Shape | Straight |
| Connection Type | Threaded |
| Maximum Working Pressure (Psi - 3 Decimals) | 5000.000 |
| Overall Length (Decimal Inch) | 2.2900 |
| Epa Watersense Certified | No |
| Series | H ISO-B |
| Valve/Non-Valved | Valved |
| Body Diameter (Inch) | 1/4 |
| Hose Diameter (Inch) | 9/16 |
| UNSPSC Code | 40141734 |
| MSC Part # | 55371686 |
| Mfr Part # | 2HOF3 |
| Country of Origin Country of Origin is subject to change | UNITED STATES |
