Alvord Polk - #2/0 Pin, 0.1462" Diam, 0.1137" Small End, 0.1562" Diam Straight Shank, 1-9/16" Flute, Taper Pin Reamer
Item #: 70698477
Brand: Alvord Polk
Model #: 03805
Features and Benefits
Helical flute reamers are used for reaming taper pin holes in blind and through-hole operations. These flutes are designed with a high spiral construction for reduced chip packing.
| Product Specifications | |
|---|---|
| Taper Pin Size (Number) | #2/0 |
| Small End Diameter (Decimal Inch) | 0.1137 |
| Reamer Diameter (Decimal Inch) | 0.1462 |
| Flute Type | Helical |
| Shank Type | Straight |
| Overall Length (mm) | 65 |
| Overall Length (Inch) | 2.5620 |
| Flute Length (mm) | 40 |
| Flute Length (Inch) | 1.5620 |
| Number of Flutes | 3 |
| Shank Diameter (mm) | 3.97 |
| Shank Diameter (Inch) | 0.1562 |
| Spiral Direction | Left Hand |
| Cutting Direction | Right Hand |
| Reamer Material | High Speed Steel |
| Reamer Finish/Coating | Bright |
| Material Application | Mild Steel |
