Die Drill Bit: 0.2677″ Dia, 132 °, Solid Carbide Multilayer TiAlN Finish, Series B978F
Item #: 58476789
Brand: Kennametal
Model #: 1950974
Product Specifications
| Drill Bit Type | Straight-Flute |
| Drill Bit Size (mm) | 6.80 |
| Tool Material | Carbide |
| Coating/Finish | Multilayer TiAlN |
| Flute Length (Decimal Inch) | 2.6378 |
| Flute Length (mm) | 67.00 |
| Drill Point Angle | 132 |
| Overall Length (mm) | 105.00 |
| Shank Diameter (Decimal Inch) | 0.3150 |
| Shank Diameter (mm) | 8.00 |
| Coolant Through | Yes |
| Drill Bit Size (Decimal Inch) | 0.2677 |
| Material Grade | KC7315 |
| Overall Length (Decimal Inch) | 4.1339 |
| Series | B978F |
| Number Of Flutes | 2 |
| Point Type | Standard |
| Cutting Direction | Right Hand |
| Coolant-Hole Shape | Round |
| Drill Point Length (mm) | 1.42 |
| Drill Point Length (Decimal Inch) | 0.0559 |
| Maximum Drilling Depth (Decimal Inch) | 2.2400 |
| Maximum Drilling Depth (mm) | 57.00 |
| Shank Length (Decimal Inch) | 1.4173 |
| Shank Length (mm) | 36.00 |
| Flute By Diameter Ratio | 8xD |
