Kennametal - 12" Cut Diam, 2" Arbor Hole, 4.5mm Max Depth of Cut, 45° Indexable Chamfer & Angle Face Mill - 24 Inserts, HNGJ 0905ANENLD Insert, Right Hand Cut, 24 Flutes, Series KSHR
Item #: 59672873
Brand: Kennametal
Model #: 3494650
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (Inch) | 12 |
| Cutting Diameter (mm) | 304.80 |
| Cutting Diameter (Decimal Inch) | 12.0000 |
| Arbor Hole Diameter (mm) | 63.50 |
| Arbor Hole Diameter (Inch) | 2 |
| Arbor Hole Diameter (Decimal Inch) | 2.5000 |
| Lead Angle | 45 |
| Overall Height (Decimal Inch) | 3.1500 |
| Insert Compatibility | HNGJ 0905ANENLD |
| Series | KSHR |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 4.50 |
| Maximum Depth of Cut (Decimal Inch) | 0.1770 |
| Number of Cutter Inserts | 24 |
| Insert Holding Method | Screw |
| Cutter Style | KSHR |
| Number of Flutes | 24 |
| Hub Diameter (Decimal Inch) | 9.0160 |
| Maximum Body Diameter (Decimal Inch) | 12.4330 |
| Maximum RPM | 2090 |
| Cutting Direction | Right Hand |
| Pitch | Coarse |
