Seco - Shell Mount Connection, 0.5512" Cutting Width, 0.5906" Depth of Cut, 63mm Cutter Diam, 0.8661" Hole Diam, 3 Tooth Indexable Slotting Cutter - R335.18 Toolholder, LNK.. 08.. Insert, Right Hand Cutting Direction
Item #: 60147097
Brand: Seco
Model #: 07858
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Shell Mount |
| Cutting Width (mm) | 14.00 |
| Cutting Width (Decimal Inch) | 0.5512 |
| Maximum Depth of Cut (mm) | 15.00 |
| Maximum Depth of Cut (Decimal Inch) | 0.5906 |
| Cutter Diameter (mm) | 63.00 |
| Cutter Diameter (Decimal Inch) | 2.4803 |
| Hole Diameter (mm) | 22.00 |
| Hole Diameter (Decimal Inch) | 0.8661 |
| Number of Teeth | 3 |
| Toolholder Style | R335.18 |
| Series | R335.18 |
| Insert Style | LNK.. 08.. |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 6 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Maximum RPM | 11900 |
| Minimum Cutting Width (Decimal Inch) | 0.5512 |
| Maximum Cutting Width (Decimal Inch) | 0.5512 |
| Maximum Cutting Width (mm) | 14.00 |
| Hub Diameter (mm) | 40.00 |
| Hub Diameter (Decimal Inch) | 1.5748 |
| Radius | No |
| Complete Insert Compatibility1 | LNKT 080504PPN-E05; LNKT 080504PPTN-M06; LNKT 080504PPTN4-M06; LNKT 080508PPN-E05; LNKT 080508PPTN-M06; LNKT 080508PPTN4-M06; LNKT 080516PPN-E05; LNKT 080516PPTN-M06; LNKT 080520PPN-E05; LNKT 080520PPTN-M06; LNKT 080524PPN-E05; LNKT 080524PPTN-M06 |
