Seco - Arbor Hole Connection, 0.1575" Cutting Width, 0.535" Depth of Cut, 63mm Cutter Diam, 0.8661" Hole Diam, 4 Tooth Indexable Slotting Cutter - 335.19 Toolholder, SNHQ 1102L, SNHQ 1102R Insert, Right Hand Cutting Direction
Item #: 60149606
Brand: Seco
Model #: 31011
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Connection Type | Arbor Hole |
| Cutting Width (mm) | 4.00 |
| Cutting Width (Decimal Inch) | 0.1575 |
| Maximum Depth of Cut (mm) | 13.59 |
| Maximum Depth of Cut (Decimal Inch) | 0.5350 |
| Cutter Diameter (mm) | 63.00 |
| Cutter Diameter (Decimal Inch) | 2.4803 |
| Hole Diameter (mm) | 22.00 |
| Hole Diameter (Decimal Inch) | 0.8661 |
| Number of Teeth | 4 |
| Toolholder Style | 335.19 |
| Series | 335.19 |
| Insert Style | SNHQ 1102L; SNHQ 1102R |
| Staggered Tooth | Yes |
| Number of Cutter Inserts | 8 |
| Cutting Direction | Right Hand |
| Insert Holding Method | Screw |
| Maximum RPM | 17100 |
| Hub Diameter (mm) | 33.00 |
| Hub Diameter (Decimal Inch) | 1.2992 |
| Keyway Width (Decimal Inch) | 0.2362 |
| Keyway Width (mm) | 6.00 |
| Radius | No |
| Cutter Body Width (mm) | 8.00 |
| Cutter Body Width (Decimal Inch) | 0.3150 |
| Weldon Flat | No |
| Manufacturers Catalog Number | 335.19-063.04.22-4 |
| Complete Insert Compatibility2 | SNHQ 1102L-MM4500-M07; SNHQ 1102L-MP2500-M07; SNHQ 1102R-F30M-M07; SNHQ 1102R-F40M-M07; SNHQ 1102R-MM4500-M07; SNHQ 1102R-MP2500-M07 |
| Complete Insert Compatibility1 | SNHQ 1102L-F30M-M07; SNHQ 1102L-F40M-E05; SNHQ 1102L-F40M-M07; SNHQ 1102L-H25-E05; SNHQ 1102R-F40M-E05; SNHQ 1102R-H25-E05 |
