Seco - 10 Inserts, 100mm Cut Diam, 32mm Arbor Diam, 3.1mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 50mm High, SNHQ 1203 Insert Compatibility
Item #: 60155074
Brand: Seco
Model #: 64315
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 100.00 |
| Cutting Diameter (Decimal Inch) | 3.9370 |
| Arbor Hole Diameter (mm) | 32.00 |
| Arbor Hole Diameter (Decimal Inch) | 1.2598 |
| Overall Height (mm) | 50.00 |
| Overall Height (Decimal Inch) | 1.9685 |
| Insert Compatibility | SNHQ 1203 |
| Through Coolant | No |
| Maximum Depth of Cut (mm) | 3.10 |
| Maximum Depth of Cut (Decimal Inch) | 0.1220 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 10 |
| Insert Holding Method | Screw |
| Cutter Style | R230.19 |
| Number of Flutes | 10 |
| Rake | Negative |
| Hub Diameter (mm) | 77.00 |
| Hub Diameter (Decimal Inch) | 3.0315 |
| Keyway Width (mm) | 14.40 |
| Keyway Width (Decimal Inch) | 0.5669 |
| Maximum RPM | 8700 |
| Complete Insert Compatibility | SNHQ 110302TR4-M07; SNHQ 110304TR4-M07; SNHQ 110308TR4-M07; SNHQ 110312TR4-M07; SNHQ 110316TR4-M07; SNHQ 110320TR4-M07 |
