ARO/Ingersoll-Rand - 1" Stroke x 1/2" Bore Double Acting Air Cylinder - 10-32 Port, 10-32 Rod Thread, 200 Max psi, -40 to 160°F
Item #: 60939949
Brand: ARO/Ingersoll-Rand
Model #: SD05-N4B4-010
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Double Acting |
| Bore Size (Inch) | 1/2 |
| Rod Diameter (Decimal Inch) | 0.187 |
| Stroke Length (Inch) | 1 |
| Mounting Style | Nose |
| Port Size | 10-32 |
| Port Type | UNF |
| Width (Decimal Inch) | 0.6200 |
| Length (Decimal Inch) | 3.620 |
| Material | Stainless Steel |
| Seal Material | Buna-N |
| Maximum Working Pressure (psi) | 200 |
| Rod Thread Size | 10-32 |
