ARO/Ingersoll-Rand - 2" Stroke x 2-1/2" Bore Double Acting Air Cylinder - 1/4 Port, 1/2-20 Rod Thread, 200 Max psi, -40 to 160°F
Item #: 60940590
Brand: ARO/Ingersoll-Rand
Model #: SD25-N4B4-020
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Double Acting |
| Bore Size (Inch) | 2-1/2 |
| Rod Diameter (Decimal Inch) | 0.625 |
| Stroke Length (Inch) | 2 |
| Mounting Style | Nose |
| Port Size | 1/4 |
| Port Type | NPT |
| Width (Decimal Inch) | 2.6200 |
| Length (Decimal Inch) | 7.560 |
| Material | Stainless Steel |
| Seal Material | Buna-N |
| Maximum Working Pressure (psi) | 200 |
| Rod Thread Size | 1/2-20 |
