ARO/Ingersoll-Rand - 1" Stroke x 1-1/2" Bore Single Acting Air Cylinder - 1/8 Port, 7/16-20 Rod Thread, 200 Max psi, -40 to 160°F
Item #: 60940905
Brand: ARO/Ingersoll-Rand
Model #: SS15-N4B4-010
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Single Acting |
| Bore Size (Inch) | 1-1/2 |
| Rod Diameter (Decimal Inch) | 0.437 |
| Stroke Length (Inch) | 1 |
| Mounting Style | Nose |
| Port Size | 1/8 |
| Port Type | NPT |
| Width (Decimal Inch) | 1.5500 |
| Length (Decimal Inch) | 4.880 |
| Material | Stainless Steel |
| Seal Material | Buna-N |
| Maximum Working Pressure (psi) | 200 |
| Rod Thread Size | 7/16-20 |
