Sandvik Coromant - 3 Inserts, 39.3mm Cut Diam, 1-31/32" Arbor Diam, 6.3mm Max Depth of Cut, Indexable Square-Shoulder Face Mill - 0° Lead Angle, 2" High, R300-1340.. Insert Compatibility, Through Coolant, Series CoroMill 300
Item #: 61442489
Brand: Sandvik Coromant
Model #: 5738759
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 39.30 |
| Cutting Diameter (Decimal Inch) | 1.5472 |
| Arbor Hole Diameter (mm) | 50.00 |
| Arbor Hole Diameter (Inch) | 1-31/32 |
| Arbor Hole Diameter (Decimal Inch) | 1.9685 |
| Lead Angle | 0 |
| Overall Height (mm) | 50.80 |
| Overall Height (Inch) | 2 |
| Overall Height (Decimal Inch) | 2.0000 |
| Insert Compatibility | R300-1340.. |
| Series | CoroMill 300 |
| Through Coolant | Yes |
| Maximum Depth of Cut (mm) | 6.30 |
| Maximum Depth of Cut (Decimal Inch) | 0.2480 |
| Cutting Direction | Right Hand |
| Number of Cutter Inserts | 3 |
| Insert Holding Method | Screw |
| Cutter Style | RA300 |
| Number of Flutes | 3 |
| Rake | Positive (Axial) |
| Hub Diameter (mm) | 50.00 |
| Hub Diameter (Decimal Inch) | 1.9685 |
| Maximum Body Diameter (Decimal Inch) | 1.5472 |
| Number of Adjustable Pockets | 0 |
| Maximum RPM | 16900 |
| Pitch | Coarse |
| Cutting Edge Length (Decimal Inch) | 0.2480 |
| ISO Number | RA300-052C5-13H |
| Complete Insert Compatibility | R300-1340.. |
| Toolholder Material | Steel |
