Kennametal - 20mm Min Bore Diam, 200mm OAL, 16mm Shank Diam, A-STWP Indexable Boring Bar - TP.. Insert, Screw Holding Method
Item #: 62181052
Brand: Kennametal
Model #: 1098218
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Toolholder Style | A-STWP |
| Series | Screw-On |
| Minimum Bore Diameter (mm) | 20.00 |
| Minimum Bore Diameter (Decimal Inch) | 0.7874 |
| Hand of Holder | Right Hand |
| Overall Length (mm) | 200.00 |
| Overall Length (Decimal Inch) | 7.8740 |
| Shank Diameter (mm) | 16.00 |
| Shank Diameter (Decimal Inch) | 0.6300 |
| Insert Compatibility | TP.. |
| Through Coolant | Yes |
| Multi-Use Tool | No |
| Insert Holding Method | Screw |
| Rake | Neutral |
| Center to Cutting Edge (mm) | 11.00 |
| Insert Thickness (Inch) | 3/32 |
| Insert Inscribed Circle (Inch) | 1/4 |
| Rake Angle | 0 |
| Coolant Hole Thread Size (Inch) | 1/8-27 NPT |
| Complete Insert Compatibility | TP.. 110204 |
| Toolholder Material | Steel |
