Kennametal - 85.6mm Cut Diam, 3.96mm Max Depth, 1-1/2" Arbor Hole, 8 Inserts, RNGJ1605M0____ Insert Style, Indexable Copy Face Mill - RODEKA 16 Cutter Style, 16,800 Max RPM, 2 High, Through Coolant, Series Rodeka
Item #: 62882329
Brand: Kennametal
Model #: 5154915
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Cutting Diameter (mm) | 85.60 |
| Cutting Diameter (Decimal Inch) | 3.3700 |
| Maximum Depth of Cut (mm) | 3.96 |
| Maximum Depth of Cut (Decimal Inch) | 0.1560 |
| Arbor Hole Diameter (mm) | 38.10 |
| Arbor Hole Diameter (Inch) | 1-1/2 |
| Arbor Hole Diameter (Decimal Inch) | 1.5000 |
| Overall Height (mm) | 50.80 |
| Overall Height (Inch) | 2 |
| Overall Height (Decimal Inch) | 2.0000 |
| Series | Rodeka |
| Number of Cutter Inserts | 8 |
| Insert Compatibility | RNGJ1605M0____ |
| Cutter Style | RODEKA 16 |
| Through Coolant | Yes |
| Maximum RPM | 16800 |
| Hub Diameter (Decimal Inch) | 3.8120 |
| Cutting Direction | Right Hand |
| Overall Diameter (Decimal Inch) | 3.7610 |
| Maximum Cutting Diameter (Decimal Inch) | 4.000 |
