Accurate Bushing - 3-1/2" Roller Diam x 2" Width, 1-3/4" Stud Diam x 2-3/4" Length, Heavy Stud Cam Follower - Carbon Steel, 1-3/8" Thread Length, 1-3/4-12 Thread, 5" OAL, 29,660 Lb Dynamic Cap, 3 N Static Cap
Item #: 62884408
Brand: Accurate Bushing
Model #: HR-3-1/2
Exact Tooling IR#: 04
| Product Specifications | |
|---|---|
| Type | Heavy Stud Cam Follower |
| Roller Diameter (Decimal Inch) | 3.5000 |
| Roller Diameter (Inch) | 3-1/2 |
| Roller Width (Decimal Inch) | 2.0000 |
| Stud Diameter (Decimal Inch) | 1.7500 |
| Dynamic Load Capacity (Lb.) | 29660 |
| Static Load Capacity | 3 |
| Length (Decimal Inch) | 5.000 |
| Thread Size | 1-3/4-12 |
| Material | Carbon Steel |
| Flange Diameter (Inch) | 2-3/4 |
| Stud Length (Inch) | 2-3/4 |
| Thread Length (Inch) | 1-3/8 |
